Sliding doors integrated into wall paneling

Specification

The sliding door integrates into the boiserie through two different systems: FILA hides the rail completely inside the wall, while PARI runs on a wall-mounted rail with a pelmet.

Mechanism

A concealed sliding mechanism embedded in the wall, with no jambs or architraves visible

Invisible-rail system — FILA

A fully concealed rail; minimum 40 mm floor clearance and 12 mm side reveal, with 120 mm or 170 mm module dimensions depending on partial or total opening; minimum leaf width 600 mm, maximum 1000 × 3000 mm

Visible-rail system — PARI

A separate system, with a wall-mounted rail and pelmet: PARI 11 (1 way, 1 rail), PARI 11T (with open frame), PARI 11C (with side stop columns), PARI 11CT (both), PARI 21 (2 way, 1 rail) and PARI 22 (2 ways, 2 rails); minimum leaf width 600 mm, maximum 1250 × 3000 mm

Boiserie integration

Hinged closures integrate with the wall panelling too, in pull or push versions, with hinges fully recessed inside the frame to avoid cracks in the wall finish

Frames integrated into the panelling

TN Plus, TNP INVERSO, TecnoSecret and Inner X1, in pull-side or push-side versions; the TecnoSecret frame is only available in the Metal finish

Integration layouts

Door integrated on 3 sides, flush-to-ceiling integrated door, lambris, or a technical compartment
